DBRLS - Duralite Black SS Ringlock Spinning Guides
Couldn't load pickup availability
- Typhoon™ Guide’s high ring location is ideal for spinning and casting applications
- Available in solid titanium alloy and 316SS frame material
- Quad-Leg design increases stability
- Increased material gauge adds strength
- Ring Lock™ system eliminates ring loss
Measurement Key:
Height A: Bottom of the foot to bottom of the ring ID
Height B: Bottom of the foot to top of ring ID
Height C: Total guide height
DURALITE RING |
|
|
||||||
Model |
Model |
Height A |
Height B |
Height C |
Weight |
Ring ID |
Foot |
Total Length |
DCRLS-8 |
DBRLS-8 |
4.69 mm |
10.09 mm |
12.06 mm |
0.5 gm |
5.4 mm |
6 mm |
21.35 mm |
DCRLS-10 |
DBRLS-10 |
5.52 mm |
12.52 mm |
14.91 mm |
1.0 gm |
7 mm |
6.9 mm |
23.85 mm |
DCRLS-12 |
DBRLS-12 |
6.4 mm |
14.75 mm |
17.37 mm |
1.4 gm |
8.35 mm |
9.2 mm |
30.40 mm |
DCRLS-16 |
DBRLS-16 |
8.74 mm |
19.24 mm |
22.43 mm |
2.4 gm |
10.5 mm |
9.9 mm |
34.5 mm |
DCRLS-20 |
DBRLS-20 |
10.74 mm |
23.77 mm |
26.23 mm |
4.1 gm |
13.03 mm |
12.63 mm |
49.23 mm |
DCRLS-25 |
DBRLS-25 |
17.6 mm |
34.35 mm |
39.51 mm |
7.1 gm |
17.75 mm |
13.54 mm |
56.68 mm |
DCRLS-30 |
DBRLS-30 |
20.95 mm |
44.42 mm |
48.88 mm |
10.5 gm |
23.47 mm |
16.5 mm |
67.7 mm |
DCRLS-40 |
DBRLS-40 |
27.84 mm |
55.95 mm |
61.03 mm |
15.5 gm |
28.11 mm |
16.8 mm |
71.91 mm |
DCRLS-50 |
DBRLS-50 |
37.50 mm |
78.00 mm |
83.00 mm |
25.0 gm |
40.40 mm |
22.0 mm |
88.0 mm |
